#522 – High Current Power Supplies with Fredrik Kensander

Podcast: Play in new window | Download

Subscribe: Apple Podcasts | RSS

Welcome Fredrik Kensander of KraftPowercon!

• Fredrik lives in Sweden, one of our first guests from there (Simone Giertz is also from Sweden originally, but now lives in the US)
• KraftPowercon makes large scale Switch Mode Power Supplies (SMPS) that are in the range of 100-200 kW output.
• Here is a datasheet of an example produce
• There are a range of different industrial uses
  • HV cleaning with smokestack
  • Electrical Preciptator (see them working on YouTube)
  • High current electroplating
• The high current unit can go as high as 30 kA at 10V
• This is used for copper plating in PCB manufacturing
• The pulse mode helps to get the plating to happen down into high aspect ratio vias.
• Reverse pulse plating use sub-microscecond pulses.
• These supplies also found a use in ballast water treatment on ships. The 3 phase power on ships is higher, so they need to have more margin in designs.
• Safety in the lab includes plastic covers for dangerous sections, as well as the case being IP44 with front panel on.  The lab gets hot because they’re often burning so much power.
• Manufacturing is on site, but the PCB assemblies are done elsewhere. It’s the integration and testing.
• Calibration is either done on test stands or in the units that are self calibrating.
• What’s the architecture of a device like this
  • EMC filter
  • 24v digital board
  • 3 phase goes to powermodule
  • 700-800V DC
  • Half bridge with IGBTs
  • 37 kHz switching
  • Snubber
  • 5-10W
  • Reverse recovery on the diodes
  • Inductor
  • Current sensor
  • Hall effect
  • Isolation back to the control side of the board
• The control loop needs to respond within 1 pulse, which is roughly 27 uS.
• Pulse module is different, it has a lot of caps and an H bridge to deliver the pulses.
• Supply chain for a device like this is the “secret sauce” of the company.
• Founding of company was in 1935
• They received a request to fix a 1937 battery charger.
• Fredrik got in touch with Chris writing about “Zephyr without the RTOS part”, trying to use similar methods that Zephyr does without taking on the entire RTOS.
• He is the software manager at KraftPowercon and working on managing 40 different firmware versions.
• He moved them from SVN to Git
• Trying to make the implementations all modular
• Autosar framework
• Replicating the Zephyr API but maybe not using the whole thing
• Using different interrupts
• Profibus
• Processor on each power control module
• PRU on the AM3358 (Beaglebone Black)
• Jay Carlson talking about STM32MP1
• Measuring with scope
• Unit testing each module
• Test the output that might be going to the IGBT gate
• The stack is multiple modules
• KraftPowercon is looking for more people
• Power factor correction (PFC)
• Rick Hartley talking about differential pairs at Altium Live
• Find Fredrik on LinkedIn
• Or on Facebook
