#501 – Discussing the Open Source PDK with Tim Ansell

Play

Podcast: Play in new window | Download

Subscribe: Apple Podcasts | RSS

Welcome back, Tim ‘Mithro’ Ansell!

  • Tim has been on the show twice before:
    • First time was talking about microcontroller and making a device out of that
    • Second time was talking about FPGAs
    • Third time is looking at creating the ASIC
  • Tim says the next level down will be making the actual chips like Sam Zeloof, but he prefers bits to atoms.
  • Talk at Chaos with Bunnie about dabbling in the others’ fields, like thinking about the lifetime of software (and applying quality engineering)
  • What is an open source PDK? Github repo
  • Three main components to building an IC
    • The RTL and design (code)
    • The tools – compiler / interpreter in SW
    • How does the physics work?
  • Called the PDK – process design kit
  • In machine readable form
  • Similar to the stackup of a PCB
  • Tim likes the tool SKiDL by past guest Dave Vandenbout.
  • Mike Englehardt has been on before talking about SPICE.
  • Why were PDKs secret before? Especially since it would be very hard to reverse engineer the PDK
  • In the 80s it was open, but it changed over time. Chris posits because of VC investment? Now it’s cultural that the chip industry is not open
  • “Open source has won in the sofware world” and the arguments feel the same
  • QuickLogic officially supporting their tools with open source tools, as stated in a blog post by CEO Brian Faith
    • We are still taking entries to win a board from episode 500
  • RISC V ISA (instruction set architecture)
  • “The secret power of open source means engineers don’t have to spend time talking to lawyers”
  • Open source standardizes legal equations
  • The ASIC world has many groups of lawyers
  • Only ideas that people are extremely confident about will get explored
  • Moore’s law slowing down, compute needs growing
  • Taking risks is hard because of all the roadblocks
  • RISC V has opened up the ISA space to try exploring ideas that others had written off as bad ideas
  • Tim gave a FOSSi “Dial Up” talk, which we will refer to at different timestamps to discuss the slides he reviews.
  • Single core has flattened out for 10 years (7 minute mark on the video)
  • More cores needs more memory bandwidth
  • Power consumption issues
  • Tim is in a group the focuses on developer productivity at Google
  • That’s why they’re contributing to tools to make things faster
  • Security is also dependent upon how fast you can deploy changes
  • Making hardware accelerators using TPUs
  • Using machine learning to develop TPU
  • 130 nm came out in 99 (26 minute mark)
  • The PDK and resulting silicon will be used for areas where cost > performance, like IoT.
  • Good for microcontroller, but not a high speed
  • Beagleboard has PRUs
  • They expect some users will make specialized devices, like putting a RISC V per pin or similar.
  • What’s the plan for analog?
  • First thing released was digital standard cells, but they plan to publish low level transistor models, including parametric models. Unfortunately they are currently blocked on getting that work released.
  • What tools are available?
    • Similar to FPGA toolchain sides
    • First step for FPGA and ASIC is synthesis, like using Yosys (lead by Claire Wolf)
    • P&R is different
    • More freedom in ASICs
      • QFlow ASIC PNR (Tim Edwards)
      • FPGA PNR are different toolchains:
        • NextPNR (lead by Dave Shah)
        • VPR (grandfather of Quartus 2)
      • DARPA launched a program called IDEA (Andreas Olofsson), which resulted in another PNR for ASICs: The Open Road project
  • Tools for doing an open source flow
    • Submitted list by sine_osc
    • Magic (older than the BSD license!)
    • KLayout
    • SPICE
      • Xyce is fast
      • LTSpice used by LT designers
    • Schematic capture is still not easy (maybe KiCad?)
  • Google will be doing a free shuttle run for open source chips
  • Will be sending it to eFabless, they will bundle the shuttle
  • 40 designs total (unless they get a large response)
  • Wafer chip scale package (CSP) 4x4mm
  • 50 i/o, 40 will be for design
  • Might send back chips on castellated PCB
  • To get your design approved, it must be using the right license.
  • They will release a full list of licenses that will work, but Apache2 is guaranteed.
  • Also needs to pass DRC, which will be published in the repo soon.
  • Skywater PDK slack channel
  • Lottery system if they get more than 40 designs
  • Will be starting first run in Mid-November, Will be doing more runs after that.
  • Out of 16 mm^2, only 10 mm^2 is available. The rest will be for “the harness”, a RISC V processor that can connect ‘virtual GPIO’ to turn things on or off.
  • As a reference for size, could probably fit 10 RISC V cores on the 10 mm^2
  • In contrast to MOSIS or Europractice, they want to fab out 100 – 400 of the chips so that they can share.
  • Slack channel skywater-pdk
  • J-Core, an SH based processor
  • Power PC is now an open ISA
  • Tim has published an Inspiration document.
  • If you’re interested, you should join the mailing lists, especially the announce one.
  • The slack invite link is on the announce list. They will try to set up an invite bot for later.
  • Check out the FOSSi dial up talk series for future information about development.
  • Mohammed from eFabless will be giving a talk about Open Road and will be showcasing demo chips, which are currently out for manufacturing. These might act as good templates.
  • Need tutorials on all of the software (KLayout, MAGIC)
  • Project from University of Michigan, FASoC, treats analog design like digital design.
  • “Screaming inside their heart”
  • Craig Bishop episode
  • Adrian Tang episode
  • The physics act more ideally in the small space of silicon
  • Hoping to have a similar OSHpark for silicon
  • “Chips4makers” is one that is trying to make “the OSH Park for ASICs”, but they are more focused on retrocomputing.
  • Trying to seed and build an ecosystem
  • “The things that will be most successful in this space will be those that build on each other and work together”
  • Traditional ASIC designers should be prepared to do thing differntly
  • Can open source be profitable? IBM bought Red Hat for $30B
  • The next wave of software is “software AND”, the hardware is just a means to an end
  • Contact Tim directly: tansell@google.com
  • Better to go on the slack and ask there
