#535 – Efinix FPGAs with Sammy Cheung

Welcome Sammy Cheung, CEO of Efinix!

• Efinix makes FPGAs in a fabless model.
• They started in 2012, but really got started with their first product in 2017
• Co-founder is Tony Ngai (CTO), both he and Sammy used to work at Altera
• At first they were trying to make a higher growth company, to possibly get aquired quickly. In 2015, when Intel acquired Altera, there was a pause to all acquisition talks.
• Interestingly, Xilinx is an investor, as well as Samsung
• Building the first chip (the Trion) required Architecture, Software, IC design. All things have to work together.
• Licensing IP
• They ended up selling 1M units
• Does first chip have to be niche?
• ASSP
• Trion is big in Computer Vision (CV) and sensing. It has hardware interfaces for Cameras / MIPI interface
• Chip architecture also matters
• Many CV users wanted to put inferencing functions on board, especially because it’s fast and flexible.
• In traditional FPGAs, the routing switch is separate from the logic element. In the Efinix “Fine grain architecture”, it’s more closely coupled. See the image in this IEEE Spectrum article.
• Logic elements are more “equivalent” logic elements
• Trion on 40 nm Low Power (LP) process
• The soon-to-be released Titanium is different. It has an upgraded architecture (though it’s still XLR).
• Early users have seen a 4x improvement
• Sammy says these chips are meant as much more than a Bridge device (like a CPLD)
• Not doing a ton of IP internally, OK with pulling in other companies’ IP
• Other vendors are integrating Efinix FPGA silicon into SIPs, using Chiplet form factors.
• Simplified power bringup
• Because doing specific FPGAs to integrate with others
• Applications
  • Reconfigurable accelerator
  • Security
  • Auto
• 4 mask sets for Trion, 3 for Titanium
• Titanium is on a 16 nm process node.
• These chips are not meant for server farms, but they’re also not chasing the low end.
• Features in the Titanium
  • DSP is more complex than just a MAC block
  • Targeting DSP blocks
  • Soft IP offerings
  • RISC V
• Next 5 years they expect more processor offerings
• Can run processor at 400-500 MHz
• “Domain Specific SOC”
• The Efinix RISCV offering is based off of the Vex RISC-V design, which won the 2018 Softcore contest, designed by Charles Papon
• Efinix hopes these chips will enable AI engineers
• Will Efinix use the open toolchain discussed on The Amp Hour regularly? No plans currently. Sammy contends that super competitve devices require vertical integration.
• Efinix has a tool called the Interface Designer
• Separate core from peripherals
• Sammy is excited about interesting future applications like automotive vision. The car is a “moving supercomputer”
• Q2 events showing Titanium and Dev kits are on the way. There will be parts out in the Summer, including the first released the TI60 out in Q3.
• What are their challenges looking forward? Not money or tech, but how the company will change as they grow
